This is the documentation for ConfiForms Server/Data Center app

However, this might also work for ConfiForms cloud and in most cases it does. But please see this page to understand the differences between server and cloud versions of the ConfiForms app.

Generally available for ConfiForms form administrators with Confluence admin permissions and for users who are Confluence space admins of the space where this form is located

Manual process

You are presented with a screen similar to this


Uploading the data into the form will replace existing data. No IFTTT rules will be executed


Use case on Recovery API - How to copy the data from one form to another with the same structure


Automation

We have developed a simple Java based script that downloads the data in a RAW format from the source server/page and attempts to upload it to the target server

confiforms-migration.zip

Script is pretty simple and all you have to do is to set the following properties

 // source server details and source form name and location
static String sourceServer = "https://wiki.vertuna.com/";
static String sourceFormName = "form1";
static long sourcePageId = 64063006;
static String sourceServerUsername = "";
static String sourceServerPassword = "";

// target server details and target form name and location
static String targetServer = "http://localhost:1990/confluence/";
static String targetFormName = "form1";
static long targetPageId = 786437;
static String targetServerUsername = "";
static String targetServerPassword = "";

Full listing of the script (same as in the zip file linked earlier)

package com.vertuna.plugins.confluence.migration;

import org.apache.commons.codec.binary.Base64;
import org.apache.commons.httpclient.HttpClient;
import org.apache.commons.httpclient.HttpMethod;
import org.apache.commons.httpclient.URI;
import org.apache.commons.httpclient.UsernamePasswordCredentials;
import org.apache.commons.httpclient.auth.AuthScope;
import org.apache.commons.httpclient.methods.GetMethod;
import org.apache.commons.httpclient.methods.PostMethod;
import org.apache.commons.httpclient.methods.multipart.FilePart;
import org.apache.commons.httpclient.methods.multipart.MultipartRequestEntity;
import org.apache.commons.httpclient.methods.multipart.Part;
import org.apache.commons.httpclient.methods.multipart.StringPart;
import org.apache.commons.io.FileUtils;

import java.io.File;
import java.io.IOException;
import java.util.logging.Level;

public class MigrateFormData {
  // source server details and source form name and location
  static String sourceServer = "https://wiki.vertuna.com/";
  static String sourceFormName = "form1";
  static long sourcePageId = 64063006;
  static String sourceServerUsername = "";
  static String sourceServerPassword = "";

  // target server details and target form name and location
  static String targetServer = "http://localhost:1990/confluence/";
  static String targetFormName = "form1";
  static long targetPageId = 786437;
  static String targetServerUsername = "";
  static String targetServerPassword = "";

  public static void main(String[] args) throws IOException {
    // no logging from http client
    java.util.logging.Logger.getLogger("org.apache.commons").setLevel(Level.OFF);

    File confiformsExportFile = File.createTempFile("confiforms", "");
    confiformsExportFile.deleteOnExit();

    try {
      String sourceUrl = sourceServer + "/ajax/confiforms/rest/raw.action?pageId=" + sourcePageId + "&fd=" + sourceFormName + ":" + sourcePageId;
      System.out.println("Requesting source: " + sourceUrl);
      byte[] rawExportContents = makeRequest(sourceUrl, sourceServerUsername, sourceServerPassword, url -> new GetMethod(url));
      FileUtils.writeByteArrayToFile(confiformsExportFile, rawExportContents);

      String targetUrl = targetServer + "/ajax/confiforms/rest/raw.action";
      System.out.println("Uploading to: " + targetUrl);

      makeRequest(targetUrl, targetServerUsername, targetServerPassword, url -> {
        Part[] parts = new Part[4];
        parts[0] = (new StringPart("pageId", String.valueOf(targetPageId)));
        parts[1] = (new StringPart("subAction", "replace"));
        parts[2] = (new StringPart("fd", targetFormName + ":" + targetPageId));
        parts[3] = (new FilePart("rawFile", confiformsExportFile));

        PostMethod m = new PostMethod(url);
        m.setRequestEntity(new MultipartRequestEntity(parts, m.getParams()));
        return m;
      });
  } finally {
    confiformsExportFile.delete();
  }
  System.out.println("Done");
}

interface PrepareMethodCallback {
  HttpMethod prepare(String url) throws IOException;
}

public static byte[] makeRequest(String url, String username, String password, PrepareMethodCallback prepareMethodCallback) throws IOException {
  HttpClient client = new HttpClient();
  client.getState().setAuthenticationPreemptive(true);
  client.getState().setCredentials(AuthScope.ANY, new UsernamePasswordCredentials(username, password));

  HttpMethod m = prepareMethodCallback.prepare(url);
  try {
    m.addRequestHeader("Accept", "application/json");

    String encodedAuth = new String(Base64.encodeBase64((username + ":" + password).getBytes()));
    m.addRequestHeader("Authorization", "Basic " + encodedAuth);
    m.setDoAuthentication(true);

    int responseCode = client.executeMethod(m);
    if (responseCode == 301 || responseCode == 302) {
      String location = m.getResponseHeader("Location").getValue();
      m.setURI(new URI(location, false));
      responseCode = client.executeMethod(m);
      if (responseCode == 200 || responseCode == 201 || responseCode == 202 || responseCode == 204) {
        return m.getResponseBody();
      }
    } else {
      if (responseCode == 200 || responseCode == 201 || responseCode == 202 || responseCode == 204) {
        return m.getResponseBody();
      }
      throw new IOException("Requested to " + url + " has resulted in error. Response code = " + responseCode + ". Response contents: " + m.getResponseBodyAsString());
    }
  } finally {
    m.releaseConnection();
  }
  throw new IOException("Cannot complete request to " + url);
  }
}


And the following dependencies are configured in the maven pom.xml

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">
<modelVersion>4.0.0</modelVersion>

<groupId>com.vertuna.plugins.confluence</groupId>
<artifactId>confiforms-data-migration</artifactId>
<version>1.0</version>

<properties>
<maven.compiler.source>8</maven.compiler.source>
<maven.compiler.target>8</maven.compiler.target>
</properties>

<repositories>
<repository>
<id>atlassian-public</id>
<url>https://maven.atlassian.com/maven-external</url>
<snapshots>
<enabled>true</enabled>
<updatePolicy>never</updatePolicy>
<checksumPolicy>warn</checksumPolicy>
</snapshots>
<releases>
<enabled>true</enabled>
<checksumPolicy>warn</checksumPolicy>
</releases>
</repository>
<repository>
<id>maven-atlassian-com</id>
<name>Atlassian Public Repository</name>
<url>https://packages.atlassian.com/maven/public</url>
</repository>
</repositories>

<dependencies>
<dependency>
<groupId>commons-httpclient</groupId>
<artifactId>commons-httpclient</artifactId>
<version>3.1-atlassian-2</version>
</dependency>
<dependency>
<groupId>commons-lang</groupId>
<artifactId>commons-lang</artifactId>
<version>2.6</version>
</dependency>
<dependency>
<groupId>commons-io</groupId>
<artifactId>commons-io</artifactId>
<version>2.6</version>
</dependency>
</dependencies>

</project>

How to run/execute this

You will need Apache Maven (https://maven.apache.org/download.cgi) and Java installed on your computer, then navigating to the directory where the pom.xml file is located, via command prompt, you will need to type the following commands

mvn compile
mvn exec:java -Dexec.mainClass=com.vertuna.plugins.confluence.migration.MigrateFormData
